Lei Xun ASP Surge Protector Asafe-25 Switch Type

Lei Xun ASP Surge Protector Asafe-25 Switch TypeShanghai Leixun Power Surge Protector supplied by Wuhan Leichuang

Model AM1-80/4
SPD Port One
SPD category combination type
Power System TT-TN-IT
Rated voltage Un 220V
Continuous operating voltage Uc 385V
Nominal discharge current In (8/20 μ s) 40kA
Discharge current Imax (8/20 μ s) 80kA
Protection level Up (8/20 μ s)<2.4kV
Recommended series connected current protection device 63A/35kA
Response time ≤ 25ns
Size 2mods, DIN43880
Failure indicator green: normal red: failure

Model AM3-20/2
SPD Port One
SPD category voltage limiting type
Power System TT-TN-IT
Rated voltage Un 220V
Continuous operating voltage Uc 385V
Nominal discharge current In (8/20 μ s) 10kA
Discharge current Imax (8/20 μ s) 20kA
Protection level Up (8/20 μ s)<1.5kV
Recommended series receiving current protection device 16A/6kA
Response time ≤ 25ns
Size 2mods, DIN43880
Failure indicator green: normal red: failure

ASP Leixun Asafe-15/4 first level surge protector

Shanghai Leixun ASP primary power lightning arrester
Lei Xun ASP power lightning arrester first level 60ka series
AM1-60/3+NPE，AM1-60/1+NPE，AM1-60/2，AM1-60/4
ASPCM25A-385，

Lei Xun ASP power lightning arrester ASafe series
ASafe-15，ASafe-25，ASafe-50，ASafe-NPE

Leixun ASP power lightning arrester AM1 first level large circulation series
AM1-160，AM1-120，AM1-NPE

Leixun ASP power lightning arrester first level 80ka series
AM1-80/2，AM1-80/1+NPE，AM1-80/3+NPE，AM1-80/4

Leixun ASP power lightning arrester level 2 40ka series
AM2-40/3+NPE，AM2-40/4，AM2-40/1+NPE，AM2-40/2

Leixun ASP power lightning arrester third level 20ka series
AM3-20/2，AM3-20/4，AM3-20/1+NPE，AM3-20/3+NPE

Lei Xun ASP power lightning arrester three-level single module series
AM-24DC，AM-48DC，AM-75DC
AM3-05D-75，AM3-05D-110，AM3-05D-220
AD-L20-385-mini

Lei Xun ASP power lightning arrester/lightning socket
A6-42-0NS，A6-60-0NS，APD-06A

Lei Xun ASP Surge Protector Asafe-25 Switch Type Technical parameters
