Reflective fiber optic probe
Product Details
Fiber optic probe
For some medical and semiconductor applications, a (very) small tip is required to perform reflectance measurements. Wen Yi Optoelectronics provides two standard diameter small tip reflective probes,
1.5mm, 2.5mm, or 3.2mm, with each tip typically measuring 100mm in length.
The probe is equipped with one or six 200 μ m (optional 200~600um) illumination fibers that can be connected to a light source, and one reading fiber that can be connected to a spectrometer to measure reflections.
| model | FIB-xxx200-Y7xx-1.0 | ||
| description | Reflective probe, 1.5~3.2 mm diameter, 100 mm long, 7 x 200 μ m fiber optic, 2 m long | ||
| fiber | 7 optical fibers with a 200 μ m core, 6 optical fibers, and 1 reading fiber, NA = 0.22 | ||
| wavelength range | 200-1100nm or 400-2500nm | ||
| probe | Stainless steel cylinder, length 100mm x 1.5mm, diameter 2.5mm or 3.2mm (customizable) | ||
| connector | SMA905 connector or FC connector | ||
| sheath | Blue PVC sleeve, outer diameter: 3mm | ||
| temperature | -20 º C to 65 º C. | ||
| bend | Minimum bending radius: short-term (a few seconds) 2cm, long-term: 12cm | ||
