Ankerui AWT100 wireless communication terminal

At present, with the advantages of easy deployment, low construction cost and wide application environment, wireless technology has gradually become an important direction of network development and application in the future industrial Internet. The Ankerui AWT100 wireless communication terminal module is a new data conversion DTU launched by Ankerui Electric. Communication data conversion includes 4G, LoRa, LoRaWAN, GPS, WiFi, CE and other communication methods. The downlink interface provides a standard RS485 data interface, which can be easily connected to power instruments RTU、PLC、 Industrial control computers, etc

For factory operation and maintenance personnel, equipment networking and wiring can be considered a "major challenge": workshop pipelines are complex, high-altitude operations pose high risks, maintenance costs are high, and safety hazards are easily caused by aging lines... Especially for the renovation of old factory buildings, traditional wired networking solutions are time-consuming and labor-intensive, seriously slowing down the pace of intelligent upgrading.

Don't worry! Ankerui AWT100 wireless communication terminal makes a heavyweight debut, breaking free from wired constraints and enabling factory equipment to be efficiently connected without wiring, easily achieving data "wireless sprint" and pressing the "acceleration button" for industrial intelligence transformation!

1Ankerui AWT100 wireless communication terminal

As a "wireless data bridge" for factory equipment, the Ankerui AWT100 accurately targets pain points in industrial scenarios and supports efficient networking experiences with powerful features. First, let's take a look at the compatibility of the core protocol - it fully supports the serial port MODBUSRTU protocol and can seamlessly integrate with power instruments in the factory RTU、PLC、 Various terminal devices such as industrial control computers can be directly linked without modifying the original equipment. With the Ankerui platform protocol, data uploading to the cloud and instruction issuance to the terminal are smooth and seamless without any lag.

Figure 1AWT100 wireless communication terminal

In response to the demand for multi device collaboration in factories, its scalability is even more impressive:Support data collection for up to 30 MODBUSRTU devices. Supports the collection of a total of 3000 electrical parameters, supports 8 types of device collection templates, each template has up to 640 points, supports server MODBUS or LoRa transparent communication, supports fixed IP and dynamic domain name resolution to connect to data centers, supports transparent transmission protocols, universal mode (driver driven wheel reading, timed reporting), MQTT protocol, smart electricity wireless protocol, prepaid wireless protocol, etc., can be customized and developed.

What's even more considerate is that it adopts a compact single-mode guide rail design, which can be directly installed in the control cabinet without taking up space, with simple construction, and can be easily deployed even in narrow workshop corners, greatly reducing installation and maintenance costs. Equipped with powerful microprocessor chips and watchdog technology, it runs stably 24 hours a day without any downtime, fully adapting to the high-intensity production needs of factories.

2. Typical applications

The typical application connection is shown in Figure 2 and Figure 3. Connect the 485 device on site to the AWT100 wireless communication terminal. The AWT100 wireless communication terminal will actively collect data from the 485 device according to its own configuration and then communicate with the Ankrui server.

In the energy management area of the factory, it can connect various power instruments and energy consumption monitoring equipment, wirelessly collect voltage, current, energy consumption and other data, and cooperate with the Ankerui Energy Management Cloud Platform to achieve energy consumption statistics and energy-saving analysis, helping the factory to accurately reduce costs. Even auxiliary systems such as security and lighting in factories can achieve wireless linkage through it - security equipment detects abnormalities, immediately uploads alarm information, and triggers lighting to turn on and access control to lock, improving the overall safety protection level of the factory.

Whether it is the intelligent layout of new factories or the renovation and upgrading of old factories, AWT100 can fully adapt without the need for large-scale destruction of existing facilities or lengthy wiring schedules. It can quickly complete equipment networking deployment, allowing factories to enjoy the benefits of intelligence as soon as possible.

3. Product Certification

4. Conclusion

Factory intelligent upgrade, starting from the networking of devices that do not require wiring! Ankerui AWT100 makes data "fly", helping you save wiring costs, shorten renovation cycles, and improve operation and maintenance efficiency，Let the workersThe transformation towards industrial intelligence is simpler and more worry free!
