Shandong Hongwei Quantum Technology Co., Ltd
Textile Thermal Resistance Tester
NegotiableUpdate on 01/08
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
The textile thermal resistance tester is used for testing the physiological comfort and thermal resistance of various fabrics under normal conditions, in accordance with GB/T11048-2008 B-type machine static flat plate method; GB/T11048-1989 A method; ASTM D1518-14 6.6.1 Static Method; JIS_L1096-2010； FZ/T 73016-2013； GBT 35762-2017 and other standards.
Product Details
Instrument usage:
Textile Thermal Resistance TesterUsed for testing the physiological comfort and thermal resistance of various fabrics under normal conditions.
meet the standards
Textile Thermal Resistance TesterCompliant with GB/T11048-2008 Type B Machine Static Flat Plate Method; GB/T11048-1989 A method; ASTM D1518-14 6.6.1 Static Method; JIS_L1096-2010； FZ/T 73016-2013； GBT 35762-2017 and other standards.
Product Features:
1. Large screen color touch screen display operation. Chinese and English interface menu style operation.
2. The core components use STMicroelectronics' 32-bit multifunctional motherboard to process data.
3. Test results: thermal resistance, Kroos value, thermal conductivity, etc.
4. Built in multiple standard testing functions.
5. There is online software that can test and print instruments on a computer, as well as print curves.
Technical Specifications:
1. Measurement range of thermal resistance (RCT): 0-2.0m2 • K/W;
2. Repeatability: ± 2.5%;
3. Thermal resistance resolution: 0.00001m2 • K/W;
4. Test temperature: adjustable from room temperature+5 ℃ to 50 ℃;
5. Temperature display resolution: 0.01 ℃;
6. Preheating time range: adjustable from 0 to 999999 seconds;
7. Test time range: adjustable from 0 to 999999 seconds;
8. Test board area: 254mm × 254mm;
9. Sample area: 514mm × 514mm;
10. Test frequency: 30 batches x 20 times;
11. Dimensions: 620mm × 720mm × 800mm (L × W × H);
12. Weight: 85kg;
13. Power supply: AC220V ± 10%, 400W, 50Hz;
Scope of supply
1. 1 host
2. 1 windproof cover
3. 1 product qualification certificate
4. 1 copy of product user manual
5. 1 delivery note
6. 1 acceptance certificate
