High pressure air generator (Chinese and Western equipment) ZXFSQ-10LGY

High pressure air generator (Chinese and Western equipment) ZXFSQ-10LGY

I. Overview
The air generator uses a low-noise compressor as the air source; The instrument is equipped with a voltage regulator, and the purification system consists of a filter, a steam water separator, and a filter, which can remove impurities and water molecules from the air. It can be used as a gas supply source for various types of gas chromatographs, flame photometers, evaporative emission lamps, and nitrogen generators, and can replace steel cylinders.

High pressure air generator (Chinese and Western equipment) ZXFSQ-10LGY

2、 Main technical parameters
1. Working conditions: Power supply voltage: 220V 50Hz
Environmental temperature: 5-40C °, relative humidity ≤ 70%
No DA dust or corrosive gas pollution.
2. Air purity: oil-free grade 3
3. Output flow rate: 0-10L/min
4. Output pressure: Output 0-0.95Mpa
5. Noise: ≤ 53 decibels
6. Rated power: 900W
7. Dimensions: 620 × 360 × 660mm (L × W × H);
8. Weight: Approximately 38Kg

High pressure air generator (Chinese and Western equipment) ZXFSQ-10LGY

3、 Instrument features
1. Replace traditional GAO compressed air cylinders to make the laboratory instrument.
2. Easy to operate, start the power switch to produce gas, can be used continuously or intermittently.
3. The pneumatic system is set to three levels of cleanliness.
4. Equipped with a voltage regulator device,
5. Equipped with overvoltage protection and automatic drainage device, safe and convenient to use.
6. Equipped with normal pressure start-up.
