Changzhou Ruixin Electronic Technology Co., Ltd
HinlonCZ series smart socket
NegotiableUpdate on 04/21
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Overview: CHS315 intelligent socket is mainly used for office power and split air conditioning power control, achieving energy-saving operation modes such as temperature and time limited use, with someone turning on and no one turning off. Mainly used for remote centralized energy-saving control of electricity consumption in apartment dormitories, public institutions, commercial chain stores, and express logistics outlets.
Product Details
High precision measurement of air conditioning power consumption, with a measurement accuracy of 1.0 level.
● Remote data transmission, temperature regulation, and strategy control through RS485 interface to achieve prepaid management.
Real time monitoring of air conditioning operating parameters, including room temperature, voltage, current, power, power factor, and operating time.
● Timed control, remote automatic power on/off, remote manual control and other management.
Temperature management, automatic temperature limit management, timed temperature adjustment, automatic shutdown when the temperature exceeds the limit.
Air conditioning usage management, able to determine whether the air conditioning is allowed to be turned on based on the current situation.
● Malignant load detection function, automatically identifying the nature of the load and achieving automatic power outage to disable illegal electrical appliances.
Remote forced power on/off, remote locking disabled.
● Implement overload protection and power-off, and alarm management for timeout use.
● Historical records of air conditioning operation status, running time, automatic or remote start stop operations, etc.
● Supports single-phase split hanging and three-phase split cabinet machines.
| power supply | 220VAC mains power supply, C-phase power supply |
| Static power consumption | <1W |
| Temperature measurement range | -5℃ -60℃ |
| Current measuring range | Hang up 0-16A; Single/three-phase cabinet machine 0-60A |
| Accuracy | Voltage, current, active power, active energy: Level 1, temperature error ± 1 ° |
| work environment | Working temperature: (-10-60 ℃) Relative humidity: ≤ 75% No condensation |
| isolation | Output, input, and power supply to casing>5M |
| immunity | Fast transient pulse ± 2KV; Surge index ± 2KV; Air discharge ± 8KV |
