Xinxiang Shouchuang Machinery Co., Ltd
TH and HL type chain bucket elevator
NegotiableUpdate on 07/01
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
TH and HL type chain bucket elevator
Product Details
TH and HL type chain bucket elevators are suitable for vertically conveying powdery, granular, and small block shaped materials with low grinding properties, such as grains, coal, cement, crushed ores, etc., with a maximum lifting height of 40m.
The characteristics of TH and HL type ring chain bucket elevator ring chain bucket lifting are: simple structure, smooth operation, scoop type loading, mixed or gravity unloading, combined sprocket wheel rim for easy replacement, sprocket wheel rim with special treatment for long service life, if gravity automatic tensioning device is used in the lower part, it can maintain constant tension, avoid slipping or chain detachment, and at the same time, it has certain tolerance to effectively protect moving parts when the hopper encounters resistance. The material temperature does not exceed 250 ℃. The TH type is designed and manufactured according to the JB3926-85 "Vertical Bucket Elevator" standard, and should be prioritized for use. Except for the connection dimensions, the chain, sprocket, and tensioning device of the HL bucket elevator are the same as those of the TH type.
Technical parameters of TH and HL bucket elevators:
|
model |
HL300 |
HL400 |
TH315 |
TH400 |
TH500 |
TH630 |
TH800 |
TH1000 |
|||||||||
|
Type of hopper |
Q |
S |
Q |
S |
Zh |
Sh |
Zh |
Sh |
Zh |
Sh |
Zh |
Sh |
Zh |
Sh |
Zh |
Sh |
|
|
Conveying capacity（m3/h） |
24 |
48 |
45 |
47 |
21 |
36 |
36 |
56 |
45 |
70 |
68 |
110 |
87 |
141 |
141 |
220 |
|
|
Dou Kuan（mm） |
300 |
400 |
315 |
400 |
500 |
630 |
800 |
1000 |
|||||||||
|
Dou Rong（L） |
4.4 |
5.2 |
10 |
10.5 |
3.75 |
6 |
5.9 |
9.5 |
9.3 |
15 |
14.6 |
23.6 |
23.3 |
27.5 |
37.6 |
58 |
|
|
Dou distance（mm） |
500 |
600 |
500 |
600 |
688 |
688 |
920 |
920 |
|||||||||
|
Chain specifications |
Φ18×50 |
Φ18×50 |
Φ18×50 |
Φ18×50 |
Φ22×86 |
Φ22×86 |
Φ26×92 |
Φ26×92 |
|||||||||
|
Chain wheel joint light（mm） |
630 |
630 |
630 |
710 |
800 |
900 |
1000 |
1250 |
|||||||||
|
Dou Speed（m/s） |
1.4 |
1.4 |
1.4 |
1.4 |
1.5 |
1.5 |
1.6 |
1.6 |
|||||||||
|
The largest block of material（mm） |
40 |
50 |
45 |
55 |
65 |
75 |
85 |
100 |
|||||||||
Note:
1. The bucket capacity in the table is calculated, and the conveying capacity is calculated based on a filling coefficient of 0.6.
2. TH type bucket elevator hopper usage: zh - medium deep bucket: conveying wet and viscous materials, such as sugar, wet fine sand, etc.
SH deep hopper: Conveys powdered to small block materials such as cement, sand, coal, etc.
3. The use of HL type bucket elevator hopper: Q-shallow round bottom hopper: conveying wet, easy to agglomerate, difficult to throw out materials such as wet sand, wet coal, etc.
S-deep round bottom hopper: Conveys dry, loose, and easily thrown materials such as cement, coal chunks, crushed stones, etc.
4. Tension calculation: G=40+0.232Q * H in the formula: Q conveying capacity (t/h) H lifting height (mm) G tension (kg)
