Proximity switch EI2Y30BN15POW2H/high temperature limit sensing

Proximity switch EI2Y30BN15POW2H/high temperature limit sensingThe ability to detect various metal objects refers to a position switch that operates without mechanical contact with moving parts. Its main working principle is to use the energy of electromagnetic fields to detect the presence or absence of objects in a non-contact manner. As a sensor designed specifically for working conditions, it has become a solution for mechanical limit applications in the steel metallurgy industry due to its high temperature resistance, stable and reliable signal output, and ability to adapt to harsh environments.

Product core feature: specially designed for high temperature environments
The E12Y30BN15POW2H proximity switch adopts a special alloy shell and ceramic sealing process, which can withstand high temperature environments above 150 ℃ for a long time (some models can reach 200 ℃ through special design), far exceeding the limit temperature of ordinary proximity switches at 200 ℃. It is equipped with high-temperature stable Hall elements or inductive probes inside, coupled with heat-resistant cables (such as silicone or mica insulation layers), to ensure stable operation in high-temperature areas such as steelmaking furnaces, continuous casting machine tracks, and hot rolling production lines. According to industrial test data, the product can still maintain IP67 protection level under continuous high temperature impact, with seismic dynamic performance of 10G and a lifespan of over 1 million actions, significantly reducing unplanned downtime caused by sensor failure.
Technical principles and signal processing mechanisms
This switch is based on the principle of non-contact detection, sensing the proximity of metal targets through electromagnetic fields or infrared radiation. When steel equipment (such as rolling mills and overhead crane arms) moves to the preset position, the oscillation circuit inside the switch generates a signal change due to the eddy current effect of metal objects. After being processed by a signal amplifier optimized for high temperature environment, it outputs a contactless switch signal. Compared with mechanical limit switches, E12Y30BN15POW2H avoids wear problems caused by physical contact, and has a response time as short as 0.1ms and a repeat positioning accuracy of ± 0.5mm. It is particularly suitable for extreme position control of high-speed continuous casting machine crystallizer vibration table or precision rolling mill. Its NPN/PNP dual output mode is compatible with mainstream control systems such as PLC and DCS, supports DC24V wide voltage input, and adapts to the complex electrical environment of steel plants.

Basic parameters of proximity switch E12Y30BN15POW2H

[Specification and Model]: E12Y30BN15POW2H

【 Dimensions 】: 30mm (millimeters)

: Inductive type

Detection distance: 15mm (millimeter)

: DC10-30V

: Three wire

: Metal (such as iron, steel, copper, aluminum, etc.)

Product application industry

Steel plants, power plants, cement plants, mines, and similar high-temperature industries, as well as high-temperature environments and high-temperature metal objects

characteristic:

Environmental temperature -40--+200 ℃

Specifications M12, M18, M30, SP80, SP140

The detection distance can be selected from 1mm to 40mm.

Silicone cable and PTFE cable

Induction method: flush installation, non flush installation

Output mode: PNP/NPN NO/NC DC NO/NC AC NO/NC

　　Proximity switch EI2Y30BN15POW2H/high temperature limit sensingIn depth analysis of typical application scenarios in steel plants

1. Alignment control of continuous casting machine segments

The centering accuracy of the fan-shaped roller conveyor directly affects the quality of the continuous casting billet during the forming process. E12Y30BN15POW2H is installed on both sides of each roller track to detect hydraulic cylinder displacement in real-time. When the roller gap deviation exceeds the threshold, a correction signal is immediately triggered. A case study of a steel plant renovation shows that after adopting this switch, the centerline offset of the casting billet decreased from ± 3mm to ± 0.8mm

2. Steel coil diameter monitoring of hot rolling line coiling machine

When high-temperature steel coils enter the coiling station after laminar cooling, it is necessary to accurately determine that the coil diameter has reached the set value. Traditional photoelectric sensors are susceptible to water mist interference, while high-temperature resistant proximity switches are directly installed near the reel, achieving closed-loop control of the reel diameter by detecting metal marking points on the rotating bracket.

3. Rotation limit of blast furnace distributor

The rotation angle of the top distributor of the blast furnace directly affects the uniformity of the distribution of raw materials inside the furnace. In an environment where the furnace top temperature remains at 400 ℃, E12Y30BN15POW2H is installed on the rotating platform in a redundant configuration, double confirming the three key positions of 0 °, 90 °, and 180 ° to ensure that the contactless signal is not affected by furnace dust.
